11KW Floor-Mounted EV Charger 16A Electric Vehicle Charging Station
Quick Detail:
Model Number: GS11-AC-B01
Rated Voltage: 380V AC
Rated Current: 16A
Rated Output Power: 11kw
Charging Port: Type 2 Cable
Cable Length: 3.5M/Customized
Communication: 3G/4G/5G, WIFI or Bluetooth Optional
Start Mode: Plug and Play/RFID card/App
Function: APP Control, screen display, Voltage Monitoring
Specifications:
| Product Name | EV Charging Station (WallBox) | |||
| Data | Model | GS7-AC-BO1 | GS11-AC-BO1 | GS22-AC-BO1 |
| Input | Power Supply | 1P+N+PE | 3P+N+PE | 3P+N+PE |
| Rated Voltage | 200~220V AC | 380~400V AC | 380~400V AC | |
| Rated Current | 32A | 16A | 32A | |
| Output | Output Voltage | 200~220V AC | 380~400V AC | 380~400V AC |
| Output Current | 32A | 16A | 32A | |
| Rated Power | 7KW | 11KW | 22KW | |
| Package | Unit Size | 340*285*147mm | ||
| Package Size | 570*350*310mm | 570*350*310mm | 570*350*310mm | |
| Net Weight | 3.8KGS | 4.5KGS | 4.5KGS | |
| Gross Weight | 6.5KGS | 6.5KGS | 6.5KGS | |
| Communication | WIFI | Optional | ||
| 3G/4G/5G | Optional | |||
| OCPP | OCPP 1.6 Json (OCPP 2.0 Optional) | |||
| User Interface | Charging Port | Type 1/ Type 2 | ||
| Cable Length | 3.5M or customization length | |||
| LED Indicator | White/Green/Black/Blue/Orange/Purple/Customized | |||
| Start Mode | Plug&Play / RFID Card / APP | |||
| Emergency Stop | YES | |||
| Environment | Installation | Wall-mounted Pole Mounted | ||
| Work Temperature | -25℃-+50℃ | |||
| Work Humidity | 5%-95% | |||
| Work Altitude | <2000M | |||
Why Choose Us?
1. More competitive price
Integrated R&D production and sales in one, can supply more competitive price for customer.
2. Efficient Production capacity
Our employees are all skilled and experienced, who can produce substantial qualified products in a shorter time, which minimize the lead time of customer order.
3. Customization support
Outer shell shape color customization available and logo customization available Etc, which meeting a large variety of customization request of customers.
4. Easy to operate
Factory pre-commissioning of network settings– ready to connect out-of-the-box.
5. High quality and complete after-sales service.
Cautions:
Electrical Hazard/Fire Hazard
The charger's socket or charging gun (including the charging cable) must be regularly inspected for damage, and the casing must be inspected for damage.
• If the charger is damaged, it must be switched off immediately and replaced .
Do not perform charger repair or replacement without authorization, only by the manufacturer.
Do not modify or modify the charger without authorization.
Do not remove safety symbols, warning tips, nameplates, signs or pipeline marks.
|
|
